SKU: TIMH-80-T
Straightpoint® 80 T Running Line Dynamometer - TIMH80T
Straightpoint® 80 T Running Line Dynamometer - TIMH80T!
SKU: TIMH-80-T
Straightpoint® 80 T Running Line Dynamometer - TIMH80T
Straightpoint® 80 T Running Line Dynamometer - TIMH80T!
Specifications
Specifications
- Load capacity: 176,000 lbs.
- Wire rope diameter: 1-5/8" - 2"
- Manufacturer name: Crosby Straightpoint
- Brand part number: TIMH10T / 2789133
- Standards: IP67
- Operating temperature: -10° to +50°C | 14° to 122° F
- Accuracy: +/- 2% of Full Scale
- Product weight: 168 lbs.
Description
Description
This running line tensionmeter from Straightpoint is a smart way to measure tension, line in/out speed, and distance for wire rope with 1-5/8"-2" diameter with a 80-ton maximum load rating. It is particularly useful in situations where there is no anchor or dead end on the line to rig a Straightpoint Radiolink or Loadlink digital dynamometer to measure tension force. This particular model (Straightpoint part #TIMH10T & Crosby part #2789133) has an output that connects to Straightpoint's SW-HHP handheld device (sold separately) or Straightpoint INSIGHT computer software (sold separately). For line out & speed, SW-MWLC software is required. This premium 80-ton running line dynamometer is made from corrosion resistant stainless steel and ideal for dockside, marine, offshore, towage, and salvage applications. We also offer a completely wireless running line dynamometer with the same wire rope dimension/load ratings.
