SKU: PSN-2020
20' x 20' ANSI A10.11 Personnel Safety Net | 17,500 lbs.
$1,225.00
Net Size:
Blazing Fast Shipments
Shipping & ReturnsTailored Business Programs
Partner with UsCustom Netting Solutions
Build Your Cargo NetPayment Options
Specifications
Load Capacity: 17,500 lbs.
Size: 20' x 20'
Minimum Wire Rope Diameter: 3/8"
Width: 20'
Length: 20'
Mesh Size: 3-1/2"
Material: Polyamide
Color: Black
Product Weight: 46 lbs.
Standards: Meets or exceeds ANSI A10.11 fall protection comliance.
Brand: InCord
Shipping and Returns: This item cannot be returned due to safety risks associated with used materials.
Additional Info: Approximate strength: 17,500 lbs.
Cord diameter: 5 mm
Hook size: 4-3/4" (120 mm) Snap Hooks (included)
UV Rating: 300kLy
Cord diameter: 5 mm
Hook size: 4-3/4" (120 mm) Snap Hooks (included)
UV Rating: 300kLy
Description
Personnel Safety Net - 20' x 20'
This 20' x 20' square personnel safety net protects larger floor openings and equipment wells with knotted high-tenacity nylon mesh rated to a 17,500 ft-lb dynamic drop.
Built for Fall Protection
- Industrial-Grade Nylon Mesh: 3.5" (90 mm) diamond mesh knotted from #120 (5.0 mm) high-tenacity nylon cord, solution-dyed black and weighing 0.0650 lb/ft².
- Heavy-Duty Border Construction: A 1/2" high-tenacity nylon rope, rated to 6,700 lb, is sewn around the entire panel perimeter.
- Staggered Quick-Connect Hooks: Attachment hooks, staggered along the perimeter and spaced 36 in. on-center along the length and 24 in. on-center along the width, for fast, secure linking to adjacent panels.
Tested to Industry Standards
- Certified to ANSI A10.11: Passes the 17,500 ft-lb dynamic drop test (350 lb weight, three drops, 50 ft, into a 17×24 ft bordered net).
- OSHA-Aligned Installation: Designed to meet OSHA rules for personnel net systems.
- NFPA 701 Method 2: Flame-retardant treated, solution-dyed black.
- 300 kLy UV Rating: Built to withstand prolonged sun exposure.
Questions?
Looking to add debris protection? Check out our Personnel Safety Net w/ Debris Liner or our full debris netting selection. Installation hardware, including 3/8" galvanized aircraft cable and snap hooks, is available separately. Our sales team is happy to answer any questions.
Debris Net vs Safety Net: Which Construction Net Do You Need?
Add the Essentials
Complete your order with these essentials, compatible with:
20' x 20' ANSI A10.11 Personnel Safety Net | 17,500 lbs.
My Cart:
$199
-
ANSI-Tested Fall Protection
InCord personnel safety nets comply with ANSI A10.11-2010 and meet or exceed OSHA requirements. Rated to withstand dynamic loads of 17,500 ft-lb and manufactured in an ISO 9001:2015-certified facility, these are fall protection nets built for where failure isn't an option.
-
Highest Grade Materials in the Industry
Built from high-tenacity polyamide, this 5mm knotted nylon safety net delivers exceptional strength in a lightweight design. A 6,700 lb. minimum tensile strength synthetic rope reinforces the border, while zinc-plated snap hooks provide secure, corrosion-resistant attachment. Made in the USA by InCord.
-
Safety Netting Built to Your Specifications
Start BuildingWhen standard netting won't fit the job, we have custom safety netting solutions built to your exact specifications. Made in the USA and designed for a wide range of applications, you can dictate size, accessories, and more. Build the perfect nets for your job.
-
