SKU: BTAS516-D
Bolt Type Anchor Shackle - Chicago Hardware - 5/16" Galvanized Steel - .75 Ton
Bolt Type Anchor Shackle - Chicago Hardware - 5/16" Galvanized Steel - .75 Ton!
SKU: BTAS516-D
Bolt Type Anchor Shackle - Chicago Hardware - 5/16" Galvanized Steel - .75 Ton
$13.69
Shackle Sizes:
Blazing Fast Shipments
Shipping & ReturnsTailored Business Programs
Partner with UsQuestions? Need it custom?
We Can Help!Payment Options
Specifications
Working Load Limit: 0.75 ton
Safety Factor: 6:1
Inside Width: 1.31"
Inside Height: 1.25"
Mouth Width: 0.53"
Shackle Size: 5/16"
Pin Size: 3/8"
Material: Drop-Forged Steel
Finish: Galvanized
Type: Bolt Type Anchor
Product Weight: .22 lbs.
Standards: Meets or exceeds all requirements of ASME B30.26, Federal Specification RR-C-271, & ASTM A148M.
Manufacturer Name: Chicago Hardware
Brand Part Number: 20615 0
Shipping and Returns: This item cannot be returned due to safety risks associated with used materials.
Description
Excellent for use in applications where round pin or screw pin shackles are traditionally used, but a bolt type shackle is a better choice for permanent or long-term pulling or lifting, or if there's a risk of a load sliding on the shackle pin (which can cause it to rotate). This added safety feature from the use of the bolt/nut/cotter pin combination is the reason why this shackle type is also called a safety anchor shackle.
Made in the USA of galvanized steel.
California Residents: WARNING
