Specifications
Pull Force: 1500 lbs.
Bolthold eAK-4 Asphalt Anchor Kit w/ 4 SP10-38 Anchors & Epoxy Grout
The Bolthold eAK-4 asphalt anchor kit delivers a complete, job-ready solution for anchoring fixtures directly into asphalt surfaces. This kit includes SP10-38 asphalt anchors paired with epoxy grout to ensure proper installation and dependable holding strength. Each anchor comes pre-installed with a 1" hex bolt and 1" diameter washer, making it ideal for mounting bike racks, signage, machinery, and similar equipment into asphalt.
Load anchors to no more than 80% of rated pull strength when the structure is self-supporting. If the structure applies a static pull force on the anchors, limit loading to 20% of the rated pull strength.
eAK-4 Asphalt Anchor Kit - Epoxy-Set Flush Mount Anchoring
Designed specifically for asphalt applications, the Bolthold eAK-4 kit removes guesswork by pairing SP10-38 anchors with compatible epoxy grout. The anchors install flush with the surface and feature a wide top header that prevents pull-through, while allowing mounted items to be removed cleanly without leaving surface obstructions.
Key Features
- Flush-Mount Asphalt Anchors: Install level with the asphalt surface for a clean, trip-free finish.
- Oversized Top Header: 1.4" header prevents anchors from dropping below the surface or pulling into the mounting plate.
- Pre-Assembled Hardware: Each anchor includes a 1" hex bolt and 1" washer for faster installation.
Common Applications
- Bike racks and bicycle infrastructure
- Parking, traffic, and wayfinding signage
- Machinery and equipment mounting
- Bollards and site furnishings
- Temporary or removable asphalt installations
Installation Tips
- Drill a 7/8" diameter hole to a depth of 6" for proper anchor embedment.
- Ensure the bolt length inside the anchor does not exceed 3".
- Inject epoxy grout fully and allow proper cure time before applying load.
Kit Includes:
Add the Essentials
Complete your order with these essentials, compatible with:
Bolthold eAK4 Asphalt Anchor Kit w/ 4 SP10 & Epoxy Grout
My Cart:
Customer Reviews
We installed 16 seperate bolts in an hour with no mess and no fuss. 1 hour later it was cured and we installed our stands. A+
Worked good. But once you use the epoxy grout, be ready to use the whole tube. Sets up fast in applicator.
The quality of everything looks great. I like the design of the anchors so that they don’t pull back up through baseplate holes. It cured quickly but had plenty of time to do 4 holes before noticing hardening. I can’t speak for the strength or longevity since it’s only been a week but so far I’d buy again. Also ended up using in concrete because asphalt above concrete footing was so thin about an inch.
Chris,
Thank you for taking the time to provide a review on our Asphalt Anchor Kit! We’re so happy to happy to hear this has worked for your application so far. We strive to provide our customers with top quality products and feedback like yours helps us to do so. Please reach out if we can be of assistance in the future!
-
