FS-5125 E/G 4-Hole 90 Degree Strut Angle - Electro-Galvanized
The FS-5125 E/G 4-Hole 90 Degree Strut Angle - Electro-Galvanized is built to create rigid, square connections at strut channel corners and joints. It provides consistent alignment while reinforcing framed systems that require dependable right-angle support. A solid fitting for interior applications where clean connections and repeatable results matter.
Electro-Galvanized 4-Hole 90 Degree Angle for 1-5/8" Strut Channel
This 90-degree angle fitting connects strut channel sections using standard channel hardware. With precision hole spacing and a channel-matched width, it delivers a stable connection point for interior framing systems in dry, controlled environments.
Key Features
- 90 Degree Corner Connection: Designed to join strut channel sections at square intersections.
- Four-Hole Layout: Features 1-7/8" center-to-center hole spacing for balanced fastening.
- Electro-Galvanized Steel: Intended for interior use where humidity is low.
- Standard Channel Fit: Built for 1-5/8" wide strut channel systems.
Common Applications
- Interior strut channel framing
- Electrical and conduit support systems
- HVAC structural assemblies
- Mechanical and utility frameworks
- Commercial maintenance and build-outs
Installation Tips
- Secure using channel nuts, bolts, nuts, and washers sized for 9/16" holes.
- Align channel sections squarely before tightening fasteners.
- Verify the 13/16" end distance is properly positioned at channel edges.
